SV 1200
vibro sieve
The SV-1200 Vibro Sieve is a high-performance circular screening machine designed for the efficient separation, classification, and grading of powders and bulk materials.
Manufactured entirely from AISI 304 stainless steel.
Technical Specifications
Manufactured entirely from AISI 304 stainless steel.
Technical Specifications
- Model: SV-1200
- Screen diameter: 1000 mm
- Standard number of fractions: 2
- Motor power: 1.1 kW
- Material: AISI 304 Stainless Steel (18/10)
- Dimensions (L × W × H): 1037 × 1200 × 1000 mm
- Weight: 260 kg
Flexible Screening Configuration
The SV-1000 can be configured to meet different production requirements:
Self-Cleaning Screen System
The SV-1000 is equipped with a self-cleaning ball system designed to prevent screen blockage during operation.
The SV-1000 can be configured to meet different production requirements:
- Single deck (standard) – separation into 2 fractions
- Two decks– separation into 3 fractions
- Three decks (optional) – separation into 4 fractions
Self-Cleaning Screen System
The SV-1000 is equipped with a self-cleaning ball system designed to prevent screen blockage during operation.
Applications
The SV-1200 is suitable for a wide range of industries, including:
The SV-1200 is suitable for a wide range of industries, including:
- Plastic recycling and compounding
- PVC processing
- Chemical industry
- Fertilizer production
- Detergent manufacturing
- Food processing
- Milk powder production
- Spices and flavorings
- Confectionery
- Pharmaceutical manufacturing
- Dry construction materials
- Mineral powders
- Bulk powder classification
